Gerätetyp |
Switch - 24 Anschlüsse - L3 - managed |
Gehäusetyp |
An Rack montierbar 1U |
Untertyp |
Gigabit Ethernet |
Ports |
24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
Power Over Ethernet (PoE) |
PoE+ |
Leistung |
Nicht-blockierende Switching-Kapazität: 26 Gbps Switching-Kapazität: 52 Gbps Übertragungsleistung: 38,69 Mpps |
Kapazität |
VLAN-Unterstützung: 255 ACL-Regeln: 100 LAG-Gruppen: 6 |
Größe der MAC-Adresstabelle |
8000 Einträge |
Jumbo-Rahmenunterstützung |
Ja |
Routing Protocol |
Statisches IP Routing, Policy-Based Routing (PBR) |
Remoteverwaltungsprotokoll |
SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, SSH-2, CLI |
Leistungsmerkmale |
Flusskontrolle, BOOTP-Unterstützung, VLAN-Unterstützung, IGMP Snooping, Syslog-Unterstützung, Port-Spiegelung, DiffServ-Unterstützung, Broadcast Storm Control, IPv6-Unterstützung, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP)-Unterstützung, Rapid Spanning Tree Protocol (RSTP)-Unterstützung, Multiple Spanning Tree Protocol (MSTP)-Unterstützung, DHCP-Snooping, Unterstützung für Access Control List (ACL), Quality of Service (QoS), RADIUS-Unterstützung, Uni-Directional Link Detection (UDLD), LLDP-Support, Link Aggregation Control Protocol (LACP), Dynamic VLAN Support (GVRP), Class of Service (CoS), Generic Attribute Registration Protocol (GARP) |
Produktzertifizierungen |
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ak, IEEE 802.1ab (LLDP), IEEE 802.3at |
Statusanzeiger |
Anschluß-Übertragungsgeschwindigkeit, PoE, Link/Aktivität |
